Goods Description/产品介绍
Material: PVC, 1200gsm, 1000D base fabric
Capacity:0.75 to 19.2 CBM
Temperature range: -30 to +70 deg C.
Accessories:water pipe, water outlet, air outlet hole
Packing: 1pc/PVC bag
Application:
•Temporary Storage
•Rainwater Collection
•Residential and Public Storage of Water
•Defense Water Storage Applications
•Water Treatment
•Emergency Storage and Relief
•Irrigation
•Choose PVC water tank to test bridge maximum load
•Fire fighting in forest
Futures:
1. light weight, easy operation.
2. minimum packing size, easy for transportation and storage.
3. no contamination for water, which may guarantee the quality of the material.
4. high strength of the coated fabric
5. high strength of the seams because of the high frequency melt and sealed with the same polyurethane as the tank body, so the tanks have excellent ability against air leakage and its very safety for water.
6. The houses can be easily assembled and disassembled for several times without damage, not bring out building debris.
Certificate:
DIN 53354;DIN 53363;DIN 53357;DIN 53361
Specification /水袋规格参数
No. |
size (M) |
Volume |
weight |
packing volume |
how many empty pcs can be put in a 20 feet container? |
1 |
1x1.5x0.5 |
750 |
10kg |
0.08 |
250pcs |
2 |
1x1.8x0.5 |
900 |
20kg |
0.09 |
210pcs |
3 |
2x1.5x0.5 |
1500 |
19kg |
0.1 |
190pcs |
4 |
2x3x0.75 |
4500 |
29kg |
0.11 |
200pcs |
5 |
2x4x0.75 |
6000 |
37kg |
0.12 |
160pcs |
6 |
2x6x0.75 |
9000 |
57kg |
0.14 |
130pcs |
7 |
2x7x0.75 |
10500 |
66kg |
0.22 |
80pcs |
8 |
2x8x0.75 |
12000 |
74kg |
0.26 |
70pcs |
9 |
2x10x0.75 |
15000 |
89kg |
0.25 |
70pcs |
10 |
2x12x0.75 |
18000 |
102kg |
0.15 |
120pcs |
